Application guide

Choose by workpiece material, match it to the right tool family, then start from the recorded cutting parameters. The tables below turn the catalogue feed data into a practical selection path.

Material groups5workpiece materials
Tool families4in the catalogue
Feed records20starting values
Diameter range0.05–1mm in feed table

01Selection logic

Material → family → parameters
01 Material group first

Start with the workpiece. Stainless steels and hardened alloys need wear-resistant coatings and lower surface speed; non-ferrous aluminium tolerates high spindle speed but needs efficient chip evacuation.

02 Then the tool family

Micro drills own small-diameter hole making, end mills handle profiling and slotting, reamers finish hole size, and special geometry covers step and non-standard forms. The families below are the four groups in our catalogue.

03 Then the starting parameters

Use the feed table as a starting point, not a final recipe. Adjust spindle speed and feed for your machine rigidity, tool projection and coolant, then refine by chip form and surface finish.

Material groupTool family Feed series groupRecords
Aluminium alloy 5052Micro drillsDC326 DC326 / DC426L4
Stainless SUS304 / 316Micro drillsDC326 DC326 / DC426L4
Carbon steel S45C / SS400Micro drillsDC326 DC326 / DC426L4
Alloy steel SCM / SKD (HRC 20-30)Micro drillsDC326 DC326 / DC426L4
Mould steel NAK / HPM (HRC 30-40)Micro drillsDC326 DC326 / DC426L4

02Aluminium alloy 5052

Micro drills

Starting values recorded for Aluminium alloy 5052. Values are for the series group shown; treat them as a first setup and adjust to your machine and coolant.

Series groupDiameter Spindle speedFeed Note
DC3260.05mm25,000rpm50mm/minNon-ferrous, high-speed drilling
DC3260.10mm25,000rpm100mm/min—
DC3260.50mm20,000rpm1,000mm/min—
DC3261.00mm16,000rpm1,200mm/min—

03Stainless SUS304 / 316

Micro drills

Starting values recorded for Stainless SUS304 / 316. Values are for the series group shown; treat them as a first setup and adjust to your machine and coolant.

Series groupDiameter Spindle speedFeed Note
DC3260.05mm15,000rpm30mm/minAustenitic stainless
DC3260.10mm15,000rpm45mm/min—
DC3260.50mm7,000rpm55mm/min—
DC3261.00mm5,000rpm150mm/min—

04Carbon steel S45C / SS400

Micro drills

Starting values recorded for Carbon steel S45C / SS400. Values are for the series group shown; treat them as a first setup and adjust to your machine and coolant.

Series groupDiameter Spindle speedFeed Note
DC3260.05mm25,000rpm50mm/minStructural carbon steel
DC3260.10mm25,000rpm75mm/min—
DC3260.50mm18,000rpm180mm/min—
DC3261.00mm15,000rpm750mm/min—

05Alloy steel SCM / SKD (HRC 20-30)

Micro drills

Starting values recorded for Alloy steel SCM / SKD (HRC 20-30). Values are for the series group shown; treat them as a first setup and adjust to your machine and coolant.

Series groupDiameter Spindle speedFeed Note
DC3260.05mm20,000rpm40mm/minAlloy and hardened steel
DC3260.10mm20,000rpm60mm/min—
DC3260.50mm13,000rpm100mm/min—
DC3261.00mm9,000rpm270mm/min—

06Mould steel NAK / HPM (HRC 30-40)

Micro drills

Starting values recorded for Mould steel NAK / HPM (HRC 30-40). Values are for the series group shown; treat them as a first setup and adjust to your machine and coolant.

Series groupDiameter Spindle speedFeed Note
DC3260.05mm17,000rpm35mm/minPre-hardened mould steel
DC3260.10mm17,000rpm50mm/min—
DC3260.50mm10,000rpm80mm/min—
DC3261.00mm7,000rpm210mm/min—

07Tool families

4 catalogue groups
Tool familyWhat it covers Browse
Micro drillsSolid carbide micro drills, coated and uncoated, from 0.03 mm.Series
End mills and routersMicro end mills, flat-bottom cutters and engraving tools.Series
ReamersHelical carbide reamers for finished hole size and surface finish.Series
Special and custom geometryStep drills, spotting drills, coolant-through drills and non-standard forms.Series
Data source

All dimensions on this site come from our production catalogue (11,717 part numbers).
